3 WELDING MODES

MMA (ARC), MMA (ARC) with VRD, and Lift TIG welding modes.
DIGITAL DISPLAY

Easy-to-read digital display with battery power monitor and indicator.
INVERTER TECHNOLOGY

Built with the latest inverter technology and Lithium-Ion battery pack.
QUALITY WELDING

High-quality ARC and TIG welds from a single charge.
HIGH DURABILITY

Manufactured with heavy-duty casing and visor.
COMPACT DESIGN

Lightweight for simple portability in demanding environments.
AUTONOMOUS WELDING

Welds 20x 2.5mm, 14x 3.2mm and 6x 4mm rods.
FAST CHARGING

Fully recharged in as a little as 1.5hrs.
 

ITEM NO. 05712
Battery Type: Lithium-Ion*

*Ensure a discharge/recharge cycle is performed every 3 months. Always keep welder battery above 50% charge when not in use.

Battery Capacity: 740Wh
Charger Voltage: 230v AC +/- 10%
Charging Time: 1.5hrs
Battery Output Voltage: 74v
Charging Current: 8A
Welding Current Range: 10A - 180A (MMA) / 10A - 150A (TIG)
Duty Cycle: 180A @ 10% / 130A @ 20% / 60A @ 100%
Net Weight: 11.60kg
Gross Weight: 13.00kg
Product Dimensions: 280(H) x 150(W) x 440mm(D)
Packaged Dimensions 450(H) x 280(W) x 550mm(D)
Welding Rod / Ø Electrode: 2.5mm x 300mm 3.2mm x 350mm 4mm x 450mm
Welding Capability (on full charge): 20 rods @ 85A 14 rods @ 115A 6 rods @ 160A

Supplied with 3mtr 25mm² electrode lead, Earth lead, and over-shoulder carry strap.
