SIP 12 TON MANUAL WORKSHOP FLOOR PRESS

SIP 12 TON MANUAL WORKSHOP FLOOR PRESS

The SIP 12 Ton Manual Floor Press is a floor-standing press ideal for the removal or installation of universal joints, pulleys, bearings, and wrist pins. Suitable for heavy-duty applications.

Part No. 03651

  • 12 Ton floor-standing shop press
  • Shop press has full manual operation
  • 180mm ram stroke, 918mm work range
  • Rugged steel frame for added durability
  • For the removal/installation of universal joints, bearings, pulleys, and wrist pins
  • Fully adjustable shop press workbed
  • For bending, bonding, straightening
  • Built-in Glycerine-filled manometer
  • Strong and durable construction

  • TECHNICAL DESCRIPTION
    Press Capacity 12 Ton
    Working Range 0 to 918mm
    Press Height 1787mm
    Press Width 770mm
    Press Depth 700mm
    Ram Stroke 180mm
    Bed Width 454mm
    Net Weight 48.30kg (P1) / 25.00kg (P2)
    Gross Weight 50.30kg (P1) / 26.00kg (P2)
    Packaged Dimensions 210(H) x 170(W) x 1380mm(D)/160(H) x 260(W) x 660mm(D)
