MAGMAWELD ESR 11 E6013 GENERAL PURPOSE WELDING ELECTRODE

Original price £3.06 - Original price £18.77
Original price
£6.39
£3.06 - £18.77
Current price £6.39

General Purpose Multi-Positional Welding Rod. Especially suitable for welding sheets thinner than 5 mm

APPLICATION
  • galvanized sheets and tubes
  • primer painted, painted, and slightly rusty steels
  • production of tanks and boilers
  • tube installations

Very easily operated in positional welding, including vertically-down. Good gap-bridging. Smooth arc, well suited for tack-welding due to its easy arc striking and re-striking properties. Possible to use equally well both with AC and DC. Welds are smooth, slightly concave, and blending into the base metal without undercutting.

Slag is self-releasing.

CLASSIFICATION

  • AWS SFA A-5.1 E6013
  • AWS/ASME SFA-5.1 E6013
  • DIN 1913 E43 22 R(C)3
WELDING PARAMETERS
Diameter x Length (mm) Current (A)
2.00x300 40-60
2.00x350 40-60
2.50x300 60-85
2.50x350 60-85
3.25x350 90-130
3.25x450 90-120
4.00x350 130-180
4.00x450 140-180
5.00x350 180-230
5.00x450 180-230


**Note-May come in sealed boxes.
