F-TECH FOX MOBILE FUME EXTRACTOR UNIT

Price Exc Tax

High Vacuum Mobile Welding Fume Extractor

Looking for a  compact high volume fume extractor? The F-tech Fox offers high vacuum dust and fume extraction for welding fume and grinding dust.

The F-Tech Fox is a high performance mobile extraction system designed for extraction and filtration of fumes derived from the welding processes, micro dust, vapours and odours.

 Download F-Tech Armur Mobile Fume Unit 110V c/w 3m Armoflex download





Compact modular design
• Extremely portable – 4 sturdy, swivel castors for easy manoeuvrability
in the workplace
• 110 or 230 volt models available
• Tandem motors offering pure efficiency in providing a vacuum of
over 20,000 Pa to extract and filter harmful welding or grinding dust
• Will run 2 welding torches simultaneously
• Hour meter to check running time on equipment
• Fan speed control
• Featuring ePTFE robust European manufactured filters (H 13 certified)
– the best solution for extracting larger amounts of dust. These 2
robust filters within the unit offer a very long service life. Cleaning
is carried out by automatic nozzles controlled by the differential
pressure measurement within the filter housing. ePTFE filters are
certified by the German Institute for occupational therapy
• Automatic cleaning for the filter cartridge and the
mechanical filter layer
• Dust is collected in the pull out dust tray and a mask/gloves
are provided for handling the removal of the waste

Filter efficiency ≥ 99.9%
Motor power 2 x 0.8 Kw
Rated input voltage 110V and 230V models 50-60Hz
Flow rate pressure 340m3/h
Noise levels <78 dB(A)
Dimensions 300 x 300 x 845 mm
Weight 35 Kg
Auto Stop/Start unit also available

Package Includes: F-tech 300A air cooled 4M torch, 5M PVC hose super elastic, PVC hose connectors male 45MM, Hose connector reducer, P3 Disposable mask/gloves
